FUTABA 16IZS User Manual

80
→ GO to TABLE OF CONTENTS
● Tap the [Throttle cut] button in the Linkage menu to
call the setup screen shown below.
Throttle cut
Stops the engine safely and easily.
Throttle cut provides an easy way to stop the
engine, by ipping a switch with the throttle stick at
idle. The action is not functional at high throttle to
avoid accidental dead sticks. The switch’s location
and direction must be chosen, as it defaults to "
－
－"
.
Throttle cut setting procedure
1. Tap the "INH" button.
2. Throttle cut function switch setting:
Tap the "--" button to call the <Hardware
select> screen, and then select the switch
and its ON direction.
(For a detailed description of the selection
method, see [Switch selection method] at
the back of this manual.)
3. Throttle cut position setting:
Tap the cut position button. Value input
buttons appear on the screen.
Use these buttons to adjust the cut
position rate.
●Initial value: 17%
●Adjustment range:
（
LOW
）
0%~50%
（
Middle
）
*With throttle stick at idle, adjust the rate until the engine
consistently shuts o.
To exit the setting, tap the [Throttle cut]
button.
The yellow line is the
cut position. When
the cut switch is ON,
the throttle will move
to this position.
Tapping this will pull up the
hardware selection screen.
Select the throttle cut switch
and ON-OFF direction.
This indicates the throttle stick's current
position. Throttle cut will only function
when the throttle stick is more than 1/3rd
into the slow throttle range.
Tapping this will change
INH to either OFF or ON
and activated.
●Return to
Linkage menu
This is the throttle cut
position. Tapping this
will display value input
buttons on-screen. Set
the engine stop position.

FUTABA 16IZS Specifications

General

Channels	16
Frequency	2.4 GHz
Display	Color LCD
Telemetry	Yes
S.Bus/S.Bus2	Yes
Model Memory	30
Battery	LiPo 7.4V
