Reference
Reference
Ratings
Communication method:
One-way operation system
Maximum operating range:
80m (Optimum condition)
For safety:
F/S (Throttle), ID (About 4 billion ways of pair
identifications)
Transmitter T3PL-2.4G
(FHSS system, wheel type, 3+1 channels)
*The 4th channel is used for mixing functions only.
Transmitting frequency:
2.4GHz band
Power requirement:
(Dry cell battery) Penlight x 4(6V)
Current drain:
100mA or less
Transmission antenna:
1/2λ di-pole (Built-in)
Receiver R2004GF:
(FHSS system, 4 channels)
Power requirement:
4.8V or 6V NiCd battery
Size:
26x39x10mm (excluding a projection part)
Weight:
14g
Servo S3003
(Standard servo)
Power requirement:
6V (common with receiver)
Current drain:
8mA (at 6V / Idle)
Output torque:
4.1kg-cm (57in.-oz.) at 6V
Operating speed:
0.19sec/60 degree at 6V
Size:
40.4x19.8x36mm (1.59x0.78x1.42in.)
Weight:
37.2g (1.31oz.)
Servo S3050
(Standard digital servo)
Power requirement:
6V (common with receiver)
Current drain:
8mA (at 6V / Idle)
Output torque:
6.5kg-cm (90.3oz.-in.) at 6V
Operating speed:
0.16sec/60 degree at 6V
Size:
40.0x20.0x38.1mm (1.57x0.79x1.50in.)
Weight:
49g (1.72oz.)
E.S.C. MC230CR / MC330CR
(Electronic speed control)
Operating system:
Forward, reverse, and brake operations are all
linear.
Power requirement:
Nicd battery 6-7 cells (7.2 to 8.4V)
PWM frequency:
1.5kHz (fixed)
Setting:
One-touch input by pushbutton switch. Set data is
saved to built-in EEPROM.
Current capacity (FET rating):
Forward=90A/200A, reverse=45A/100A
Size:
27.1x33.3x12.8mm (1.07x1.31x0.50in.)
(excluding protruding parts)
Silicon cord gauge size:
AWG16/AWG14 equivalent
Weight:
44/45g (1.55/1.59oz.)
(including connectors and switches)
BEC voltage:
6.0V
*Specifications and ratings are subject to change without prior notice.
NOTE: This Futaba FHSS system, including the T3PL-
2.4G transmitter and R2004GF receiver, does not work
with current Futaba FASST™ systems. Please use the
T3PL-2.4G and R2004GF in pairs. Futaba FASST sys-
tems and FHSS systems are not compatible.
