FUTABA T14SG Software Instructions

【Setting range】 ↓ THRESHOLD ～ 327.67℃ 【Setting range】 0.00℃～↑ THRESHOLD
- 3 -
Start Slot 8,16,24
8.
【All Model Types】
KONTRONIK ESC sensor function
The KONTRONIK is selectable.
Compatible with the KONTRONIK ESC sensor. The current,
voltage , capacity, RPM, temperature, BEC temperature, BEC
current and motor duty can be displayed. This sensor uses 8 slots.
Please read the PowerBox sensor instruction manual for more
information.
【Setting range】 ↓ THRESHOLD ～ 655.35Ah
【Setting range】 0.00Ah ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 250,000rpm
【Setting range】 0rpm ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 61V 【Setting range】 12V ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 500.0A 【Setting range】 0.0A ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 150℃ 【Setting range】 0℃～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 100% 【Setting range】 0% ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 150℃ 【Setting range】 0℃～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 500.0A
【Setting range】 0.0A～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 9.00V
【Setting range】 0.00V ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 8,192mAh
【Setting range】 0mAh ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 9.00V
【Setting range】 0.00V ～↑ THRESHOLD
Start Slot 8,16
The POWERBOX is selectable.
9.
【All Model Types】
PowerBox sensor function
Compatible with the PowerBox sensor. The current, voltage
(2 batteries), capacity, reception, speed, altitude, distance and
trip can be displayed. This sensor uses 16 slots. Please read the
PowerBox sensor instruction manual for more information.

FUTABA T14SG Specifications

General

Channels	14
Frequency	2.4GHz
Telemetry	Yes
Model Memory	30
Modulation	FASSTest, FASST, S-FHSS
Display	128 x 64 dot LCD
Battery	LiFe
