FUTABA T14SG Software Instructions

- 2 -
Start Slot 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,
19,20,21,22,23,24,25,26,27,28,29,30,31
【Setting range】
↓ THRESHOLD ～ +500km/h
【Setting range】
-500km/h ～↑ THRESHOLD
【Setting range】
0 ～ 3,000m （250m Step）
The SPEED-1677 is selectable.
6.
【All Model Types】
Robbe Air speed sensor function
Compatible with the Robbe
True Airspeed Sensor 450.
The air
speed and altitude can be displayed. Please read the PowerBox
sensor instruction manual for more information.
【Setting range】 ↓ THRESHOLD ～ +115℃
【Setting range】 -10℃～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ +180.0°
【Setting range】 -180.0°～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ +180.0°
【Setting range】 -180.0°～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 10.0A 【Setting range】 0.0A ～↑ THRESHOLD
Start Slot 8,16,24
The CASTLE-TL0 is selectable.
7.
【All Model Types】
Castle ESC sensor function
Compatible with the Castle ESC sensor. The voltage, current,
motor duty, RPM, BEC voltage, BEC current and ESC temperature
can be displayed. This sensor uses 8 slots. Please read the
PowerBox sensor instruction manual for more information.
【Setting range】↓ THRESHOLD ～ 327,670rpm
【Setting range】 ↓ THRESHOLD ～ 327.67A 【Setting range】 0.00A ～↑ THRESHOLD
Motor Pole or Gear Ratio
【Setting range】 0.0V ～↑ THRESHOLD
Motor Pole【Setting range】2 ～ 36 GEAR【Setting range】1.00 ～ 99.00
【Setting range】 ↓ THRESHOLD ～ 327.67V 【Setting range】 0.00V ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 327.67V
【Setting range】 0.00V ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 3,276.7V 【Setting range】 0.0V ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ +3,276.7A 【Setting range】 0.0A ～↑ THRESHOLD
【Setting range】 ↓ THRESHOLD ～ 100.00% 【Setting range】 0.00% ～↑ THRESHOLD

FUTABA T14SG Specifications

General

Channels	14
Frequency	2.4GHz
Telemetry	Yes
Model Memory	30
Modulation	FASSTest, FASST, S-FHSS
Display	128 x 64 dot LCD
Battery	LiFe
