A.Wiredconnection:Advancedsettings
1. Select "Gyro setting" on the last page of
Helicopter Model Menu
*If "CRSF" is ON in the system type of the linkage
menu, "Gyro setting" cannot be selected.
3. Home screen is displayed
To basic menu
To expert menu
To receiver
2. Select "Start"
* At this time, if Gyro is not connected to T16IZ by wire, the EQ
ID screen appears.
1
3
2
SETTING
CAUTION
Be sure to connect and disconnect the CGY760R/CGY755 and
T16IZ connection cable with the power off.
◆When copying data from Gyro A to Gyro B
Connect the gyro A to the T16IZ and press [Start]. (Enter the data of A into T16IZ)
Connect Gyro B to T16IZ and press [GY Settings Transfer]. (Put data on A into gyro B)
Select "Start" This will download
the gyro data to the T16IZ.
When "GY Settings Transfer" is
selected, the gyro setting data saved
in T16IZ is written to the gyro.
If you press Start here, the B data will be written
to the T16IZ and the A data will be lost.
