CurvesettingoperationSplinecurve
A smoother curve is made.
Setting method is same at spline and point.
Spline curve
The kind of mixing curve
PointSpline
Up to 11 or 17 points curve can be used.
(diers with function)
Initial point number: 9 points (17 points
curve), 7 points (11 points curve)
*The set points can be freely increased, decreased, and
oset.
[Rate adjustment of each point]
2. Tap to the [Rate]
i t e m . A n d s e t
t h e r a t e u s i n g
the "▼▼" "▼" "▲"
"▲▲" buttons
Repeat steps 1 through 2 and adjust the
curve.
Pointcurve(Point)adjustment
(Point)
*[Separ.] mode: Normal setting
*[Comb.] mode: Creates a left and right
symmetrical curve.
1. Tap to the item
and select the point whose
rate you want to set.
*The mark on the curve shows
the currently selected point.
Up to 11 or 17 points curve can be
used. (diers with function)
Initial point number: 9 points (17
points curve), 7 points (11 points
curve)
