FUTABA T16IZ Quick Start Guide

Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesbelow
yoursetvalue.
*The current and capacity consumption display may vary
depending on the usage conditions, so use it as a guide.
◆
ESC telemetry display screen
The ESC status is displayed. Alarm setting is also possible.
Displaymax/minvalue
Pressandholdtoreset.
Displaymax/minvalue
Pressandholdtoreset.
Taptomovetothe
currentsettingpage.
Taptomovetothe
voltagesettingpage.
Taptomovetothe
capacitysettingpage.
Taptomovetothe
rotationsettingpage.
Enterthenumberof
polesforyourmotor.
Whenenabled,thealarm
willbeactivatedinthe
followingwarningstate.
Ifthegearisdown,enter
thegearratiotodisplay
thehelicopterrotorspeed
andtheairplanegeardown
propellerspeed.
Whenenabled,thevibrator
willstartinthefollowing
warningstate.
◆ Warningstate
◆ AlarmscanbesetforVoltage,Capacity,Rotation,ESCtemperature,andThrottleusing
thesameprocedure.
ShowstheoutputlevelfromtheESC
tothemotor,notthepositionofthe
throttlestick.
Evenifthestickisinthe50%
position,theoutputmaynotbe50%
dependingontheESCsetting.
Throttlenotat0%
Lowvoltage
Overtemperature
Overcurrent
Motorlocked
Throttlesignallost
WhenthethrottlestickisnotlowwhenESCisstarted
Whenthebatteryvoltageisbelowthecutoffvoltage
WhentheESCtemperatureis110°Corhigher
Peakcurrentover
Whenthemotorlocks
Whennothrottlesignalisreceivedformorethan0.25s
Taptomovetothe
temperaturesettingpage.
Taptomovetothethrottlesetting
page.
◆ MC-9130H/Atelemetryconnectionexample
SBM-2
ESC
ToCH3
Tofreeport
Todrivebattery
Throttle
ToS.BUS2
◆ Alarmsetting
Setsthecurrenton
whichthealarm
operates.

FUTABA T16IZ Specifications

General

Channels	16
Frequency	2.4GHz
Telemetry	Yes
Voice Alerts	Yes
SD Card Slot	Yes
USB Port	Yes
Trainer Port	Yes
Modulation	T-FHSS, S-FHSS
Display	4.3-inch color touchscreen
Battery	7.4V 2000mAh
Model Memory	30 models
