Pag. 54 / 57 0MNLIBRAPROK10NPENUA 01
6. General characteristics
Mechanical Data 10 15 20 30 40 60 80
Width [mm] 555 800
Depth/height [mm] 740 / 1400
Ventilation Forced
Max current dispersion 300mA max
Noise at 1m from front (0÷100% load) [dBA] 60÷62
Applicable Standards
Refer to the “Safety and Compliance Manual ” supplied
with the UPS (0MNA141_NE).
Electrical Data 10 15 20 30 40 60 80
RECTIFIER INPUT
Rated voltage
400Vac 3-phase
Rated voltage tolerance
-25%, +20% ( 100% load)
- Battery in charge
-10%, +20% ( 100% load)
- without battery contribution
-20%, -10% ( 100% load)
Rated frequency [Hz]
50/60
Input frequency tolerance
from 45 to 65Hz
Rated current absorbed (400 V) [A]
16 24 31 46 62 93 124
Rated power absorbed (400 V) [kVA]
11 16 22 32 43 64 84
Max current absorbed at full load and with battery
recharging [A]
22 34 45 65 87 131 175
Monoblocks/ Number of Pb elements 32 / 192
Ripple voltage with recharged battery [%] Approx 0
Max recharge current [A]
Full load 2 3 4 6 8 12 16
Load 90% 5 7 9 13 18 26 36
Load 80% 7 11 14 21 27 41 56
Load ≤ 50%
15 18 29 37 37 75 75
Progressive start of rectifier (power walk-in 0-100%)
Configurable (0÷120s)
Delay of progressive start of rectifier (Power Walk-in
delay timer)
Configurable (0÷120s)
current distortion, power factor (*):
LIBRAPRO std version
25 %, ≥ 0,9
LIBRAPRO + F
5 %, ≥ 0,9
LIBRAPRO 12P
not available < 5 %, ≥ 0,93
LIBRAPRO 12P + F
not available < 3 %, ≥ 0,95
(*) load 100%, rated input voltage, and full charge battery.
