RF Module (Models 13362 /13372 only)
General
Frequency range..............................................................................................................VHF: 154-174 MHz
UHF: 450-470 MHz
Antenna impedance................................................................................................................................ 50 Ω
Operating voltage............................................................................................... 9-18 V dc, 12 V dc nominal
Decoder................................................................................................................................. CTCSS/CDCSS
Receiver (measurement procedures made per ANSI/TIA/EIA-603)
Sensitivity (12 dB SINAD)............................................................................................................... 0.25 µV
Inter-modulation ................................................................................................................................... 60 dB
Spurious response ................................................................................................................................. 55 dB
Audio output .................................................................................................................. 300 mVrms, 1 Vp-p
3 kHz deviated signal
Approvals
FCC Identifier ............................................................................................................... VHF: AIERT 17-142
UHF: AIERT 17-442
FCC Compliance..................................................................................................................................Part 90
VHF Antenna
Dimensions ......................................................................................................... Maximum 3.00 inches high
Mounting................................................................................................................................ BNC connector
Impedance.............................................................................................................................................. 50 Ω
UHF Antenna
Dimensions ......................................................................................................... Maximum 3.00 inches high
Mounting................................................................................................................................ BNC connector
Impedance.............................................................................................................................................. 50 Ω
