Installation
Mechanical Receipt Inspection
The Addressable Amplified Speaker is shipped in a cardboard container, protected from movement and
distress by a self-forming packaging material. Thoroughly inspect it as soon as possible after delivery.
In-transit damage should be immediately reported to the transportation company.
Equipment Required
Programming
• PC with Windows 95 or newer operating system.
• N
OTE: CARD Suite is not compatible with Windows NT.
• XAC1000A Programming Software (all models)
• XAC0004A Programming Cable (all models)
• 19101-024 RF Programming Kit (Models 13362 and 13372 only)
Tools
• #1 Phillips screwdriver
• 1/16-inch flat blade screwdriver (for remote volume control connection only)
Cable Installation Safety Considerations
Interconnecting, communications, and Class 2 dc power cables should be separated from electrical light
or other Class I circuits by at least 2 inches. The exception is where Class I wiring or power circuits are
run in a raceway, or are metal-sheathed or metal-clad, or are permanently separated from the conductors
of the other circuitry by a continuous and firmly fixed nonconductor such as porcelain tubes or flexible
tubing in addition to the insulation on the wire. Communications cables and in-building wiring should be
listed and marked for the purpose according to NEC Article 800.
Programming
General Description
GAI-Tronics’ CARD Suite Programming Software, Part No. XAC1000A, is needed to program some
of the functions and parameter settings of the Addressable Amplified Speaker. It allows entry of
operational programming data into your personal computer for transfer to the equipment. The
programmed data can be retrieved, edited, archived, and printed in hard copy for record keeping.
The Model 19101-024 RF Module Programming Kit is needed to program the licensed frequency and
associated TPL/DPL code into the radio.
CARD Suite Software Installation
The minimum system requirement necessary to support the CARD Suite Software Application is
Windows 95 or newer. However, CARD Suite is not compatible with Windows NT. The CARD Suite
Programming Application components are contained on CD-ROM. Please exit all other programs that are
running until the installation is complete.
