Programming the RF Module (19101-024 Programming Kit) - Models
13362/13372 Only
1. Disconnect the connecting cable from the RF Module. Refer to Figure 4.
2. Connect the DTXP-PAC cable assembly’s red and black leads to a 12 V dc source (battery or supply)
and plug into the 15-pin D connector on the RF Module.
3. Connect one end of the 9/RTC-PAS programming cable to the PC’s serial port and the other
(modular) end to the modular receptacle on the DTXP-PAC cable.
4. Proceed with programming following instructions provided with the kit and the software help files.
Program only the frequency and PL information into the RF Module.
Mounting
1. Untwist the two nylon ties used for wire management. Unplug the quick-connect fastons from the
speaker and unplug the 11-point connector from the PCBA. The front section can now be completely
separated from the rear section.
2. Mount the rear section to any flat surface using ¼-inch customer provided screws in each of the four
0.280-inch mounting holes in the corners of the rear section. Refer to Figure 6 or Figure 7 for
mounting hole pattern dimensions. A Model 231 Pole Mounting Kit can also be used for pole or
surface mounting. Surface mounting this kit requires only two customer-provided mounting screws
and the kit includes four mounting screws needed to secure the speaker to the kit’s bracket.
