Remote Volume Adjustment (DTMF only)
Step Action Response
1 Page closure (Model 13352) or
carrier-detect (Model 13362/
13372) is detected.
The speaker assembly activates and waits for correct Page ID.
2 The correct Page ID and audio
setting is received.
The speaker assembly enables the speaker amplifier,
generates a tone for received audio setting that is broadcast
over the speaker for a preprogrammed amount of time.
3 Another audio setting is
received.
The speaker assembly generates another tone for the new
audio setting that is broadcast over the output for a
preprogrammed amount of time.
4 Page closure (Model 13352) or
carrier-detect (Model
13362/13372) is de-activated.
The speaker assembly disables the speaker amplifier, stores
the last output level setting, and returns to sleep mode.
Selective Broadcast Operation, Wrong Activation Code Received
Step Action Response
1
Page closure (Model 13352) or
carrier-detect (Model 13362/
13372) is detected.
The speaker assembly wakes up and waits for correct Page
ID.
2
An incorrect Page ID is
received.
The speaker assembly returns to sleep mode after a
preprogrammed amount of time.
