Page 20 of 32
Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A
d:\radio products-draft\gtc 43004\43004-030a\43004-030a.doc
06/05
Place the CD in the PC’s CD-ROM drive. If the “auto-run” feature on your CD-ROM drive is enabled,
the CARD Suite menu screen should appear within a few seconds. If for any reason the installation does
not start up automatically, it can be run from the Start menu. Select the S
TART button and then select
Run from the Start menu. At the prompt, type x:\Setup.exe where x represents the drive letter that is
associated with your CD-ROM drive. A CARD Suite icon should appear on the desktop display after
successful installation.
RF Module Programming Software Installation
The Model 19101-024 RF Module Programming Kit includes a software CD, two cable assemblies, and a
9-25 pin adapter. The software (labeled DTXL-PCPS-2.0) also requires Windows 95 or newer to operate.
Insert Disk 1 into the PC’s A:/ drive, and select the “.exe” file. The program will tell you when to insert
Disk 2.
Preparing to Program
Remove the speaker from the carton and position on a flat surface with the front of the speaker facing up.
Although the front section attaches to the rear section with six Phillips screws, only two screws have been
secured during the production process. Back out the two screws on the left and right side of the speaker.
All screws are captive and will remain in the front section. Lift the front section straight up and flip to the
left-hand side of the rear section. Refer to Figure 3 and 4.
