DETERMINING THE HAND OF THE DOOR
G.A.L. door operators are available for right hand doors and for left hand doors. (Center parting doors
use a variation of the left hand operator). to determine the hand of the door, stand in the lobby facing the
elevator doors. If the doors close to the left, it is a left hand door. If the door closes to the right it is a right
hand door. The left hand, center parting and right hand operators are not interchangeable. The figures
below illustrate the door hand.
G.A.L. Manufacturing Corporation December, 2007
LEFT HAND DOOR
RIGHT HAND DOOR
CLOSING
DIRECTION
CLOSING
DIRECTION
STRIKE JAMB STRIKE JAMB
