GAL MOVFR - Parameters List

7.14 Parameters list:
Pr.0 Max. Close Speed (Close Speed detection)
Unit: 0.1 Hz
Default: 30.0 Hz
Range: 0 ~ 400.0 Hz
The output frequency detection signal is on when the output frequency reaches or exceeds the
setting value.
Pr.1 Close Holding Torque (torque boost)
Unit: 0.1 %
Default: 3 %
Range: 0 ~ 30 %
Increase the setting when motor torque in low speed range is insufficient.
Pr.2 Close Holding Speed
Unit: 0.1 Hz
Default: 2.0 Hz
Range: 0 ~ 400.0 Hz
Pr.3 Close Torque (Base Freq.)
Unit: 0.1 Hz
Default: 173.0 Hz
Range: 0 ~ 400.0 Hz
This parameter is used to adjust the AC drive output (voltage, frequency) to the motor rating.
Pr.4 High Speed Close (HSC)
Unit: 0.1 Hz
Default: 19.0 Hz
Range: 0 ~ 400.0 Hz
Pr.5 Final Speed Close (FSC)
Unit: 0.1 Hz
Default: 5.0 Hz
Range: 0 ~ 400.0 Hz
Pr.6 Nudging Speed
Unit: 0.1 Hz
Default: 9.0 Hz
Range: 0 ~ 400.0 Hz
Pr.7 Close Acceleration Time
Unit: 0.1 Sec
Default: 6.0
Range: 0 ~ 320.0 Sec
The Acceleration time is used to determine the time required for the AC drive to ramp from 0 Hz to
its reference frequency (Pr.50).
