Pin
(Black)
Wire Harness
(
Main Harness
)
See Figure 1 for pin number and location.
Pin 1. (RED) Parking Light Pwr.
w/15A fuse
Used to power the parking lights. Connect this wire to Bat + 12v.
Pin
2
. (Yellow) Parking Lights Out (+)
.
Connect to
the vehicl
es parking light circuit.
If parking lights require more
than
10
amps
(not normal)
use an external
30
Amp relay.
Pin
3
. (
Blue
/
R
ed
) NC
-
2
Used for central door locks. See Figure 2, 3, 4, 5, 6 for your vehicle’s door lock
system
.
Pin
4
. (
Blue
/White) Com
-
2
U
sed for central door locks. See Figure 2, 3, 4, 5, 6
for your vehicle’s door lock system.
Pin
5
. (Blue/Yellow) NO
-
2
Used for central door locks. See Figure 2, 3, 4, 5, 6
for your vehicle’s door lock system.
Pin
6
.
(Green/Red
)
NC
-
1
Used for central door lo
cks.
See Figure 2, 3, 4, 5, 6
for your vehicle’s door lock system.
Pin
7
. (Green/White) Com
-
1
Used for central door locks. See Figure 2, 3, 4, 5, 6
for your vehicle’s door lock
system.
Pin
8
. (Green/Yellow) NO
-
1
Used for central door locks. See Figure 2, 3
, 4, 5, 6
for your vehicle’s door lock system.
Pin
9
. (Purple) Trunk output (
-
)
.
Trunk Release Output Neg. (
-
). Connect to the trunk release Neg. (
-
) trigger wire
on the vehicle’s trunk release relay. In the event that a trunk release is to be added to the
vehicle, an additional relay
and trunk release solenoid will be required.
Pin
10
. (White/Black) Arm Output (
-
)
Is a neg. (
-
) output when the alarm is triggered. Can be used to activate other
alarm triggered devices. (125 ma max.)
Pin
1
1. (White/Blue) Auxi
liary output (
-
)
This is a low current (
-
) output (125ma max). It can be used to activate the
(
-
) neg side of a relay that may be used for operating the passenger door of a shaved door vehicle, an extra trunk
release or an electric window close operation.
Connect
to a window close module (not included) with a Neg. (
-
)
input. Follow the window close module instructions for wiring to window motors. Do not connect this wire directly to
the vehicle’s window close switch. The output duration can be either 2 sec
or 15 sec per Table #1 option
8
, page 9
.
Pin
12
. (RED)
Module Power
.
w/5A fuse
Used to power the GTS
-
3RS Control Module. Connect this wire to Bat +
12v.
Pin
13
. (White) Ignition 2 output (
-
)
Used to activate an additional relay so that an IGN 2 circuit ma
y be used when
the vehicle requires its use. Not all vehicles require an IGN 2 circuit. Pin4 must be connected to the (
-
) neg terminal
of the relay. See Figure 1, option 2.
Pin
14
. (Purple/White
)
Start Enable input (
-
) input.
Connect to a good chassis gr
ound (
-
).
Pin
15
. (Black) Ground (
-
)
Connect to a good chassis ground (
-
).
Pin
16
. (Orange/White)
Handbrake (
-
).
Connect to the handbrake switch that is neg (
-
) when handbrake is set.
Pin
17
. (White/Red) Disarm Output (
-
) Ground While Running (GWR)
.
Conne
ct to the Neg (
-
) input of a security
bypass device. These devices are used in the event that the vehicle has an OEM security system that prevents
starting the vehicle without the security key. The proper security by
-
pass module for the specific vehicle ca
n be
found at
www.gallotech.com/support
. Follow the instruction that came with the by
-
pass module.
This wire is activated only during engine starting and running. When the engine is turned OFF there will be
no GWR
output.
Pin 1
8
. (Black/White) Foot Brake input (+)
(+12v) Foot Brake Switch Input Used for
auto
door lock
function
and
Start
ing
. Connect to Foot brake switch terminal that has +12v only when foot brake is depressed
.
Pin 1
9
. (Brown/Black) Door (+) i
nput
.
Pos. (+) Door Switch Input.
Connect to
a
Pos.
(
+
) Door Trigger switch. If
the
vehicle has “
-
”
Neg.
Door Trigger use the
(Brown/White, P
in 18) wire instead.
Tape or wire nut wire if not used.
Pin
20
. (Brown/White) Door (
-
) input.
Neg. (
-
) Door Trigger
switch Input.
Connect to the Neg. (
-
) Door Trigger
switch. If
the
vehicle has “+” Pos Door Trigger
,
use
the (Brown/Black), Pin 16) wire instead.
Tape or wire nut wire if
not used.
Pin
21
. (Light Blue) Tach Input
. Before connecting see Sec 1.4
“
Voltage/ T
ach signal detection Option
s
”
.
Pin 22. (Brown) Siren/Horn output (+)
.
+12v Output.
Connect to the RED Siren wire. Connect the second siren
(B
lack)
wire to a good chassis ground.
If the vehicle’s horn is used
;
connect Pin 22 (Brown) wire to the (+) pos
term
inal on the horn relay. Do not connect directly to the horn. Table #1 option
10
must be changed to either Siren
or Horn.
Installing Connector C
3
:
