Use and Maintenance Manual – Pressure-sensitive bumpers type GSBPS 6/35
3 Legislative Reference
The safety device called
PRESSURE-SENSITIVE BUMPER
consisting of the sensor type: GSBPS01, GSBPS02, GSBPS03
In combination with the control unit type: GP02/E, GP02R.T
has been designed and manufactured in compliance with the essential safety and health requirements for
people’s safeguarding. In particular, the design and manufacture provisions prescribed by the Machine
Directive 2006/42/UE, and the Electromagnetic Compatibility Directive 2014/30/UE, as well as the
European harmonized Standards for risk prevention (EN ISO 12100:2010) have been complied with. Also
taken into account have been the domestic technical specifications, in consideration of the technological
level in force at the moment of construction as well as of the technical and economical requirements.
GAMMA SYSTEM PRESSURE-SENSITIVE BUMPERS also comply with the applicable requirements of the
following Standards:
Safety of machinery - Pressure-sensitive protective devices - Part 3:
General principles for design and testing of pressure-sensitive
bumpers, plates, wires and similar devices (ISO 13856-3:2013)
Safety of machinery - Safety-related parts of control systems - Part 1:
General principles for design (ISO 13849-1:2015)
Safety of machinery - Electrical equipment of machines - Part 1:
General requirements
CEI EN 60529: 1997 + A1: 2000
Degrees of protection of casings ( degree of protection IP)
Safety of machinery - General principles for design - Risk assessment
and risk reduction (ISO 12100:2010)
Other European Directives
(EC) Standard (CE) n°1907/2006
3.1 Approvals
Pressure-sensitive bumpers formed by the sensor type GSBPS0x (x=1,2,3) and used in combination with the
control units type GP02/E or GP02R.T conform to the requirements of EN ISO 13856-3 Standard.
The sensor GSBPS0x (x=1,2,3) in combination with the control units type GP02/E or GP02R.T is a safety
component of class 3 PL “d” which meets the prescriptions of EN ISO 13849-1 Standard. According to the
destination of use and the limits of use defined by the manufacturer, it is excluded that a mechanical failure
of the sensor can lead to the loss of safety function of the devices, meaning that, even if triggered, the
internal contact of the sensor cannot make. Also excluded is the risk for cuts with the ingress of foreign
bodies inside the sensor chamber capable of impairing the sensor operation or modifying its sensitivity (force
of activation).
