Garbin 4 PRO - Page 31

Model 523 M-A-D 5 M-A-D 4 M-A-D
Electric Power
3600 W 7200 W 7200 W
Power supply
230V~;
50/60 Hz
400V~ 3N;
50/60 Hz
400V~ 3N;
50/60 Hz
Electrical
connection
type “X” type “X” type “X”
Weight
54,5 Kg 81,5 Kg 81,5 Kg
Dimensions
(mm)
635x742x690 980x836x620
980x836x620
Capacity
N° 5 trays
2/3 GN
N° 5 trays
1/1 GN
N° 4 trays
600 x 400 mm
Distance
between the
racks
75 mm 75 mm 80 mm
Max Load
6 Kg per level (food + container)
Type of electric
cable
H07RN-F
3 x 2.5 mm
²
H07RN-F
3x4 mm²/5 x 2.5
mm²
H07RN-F
3x4 mm²/5 x 2.5
mm²
Water Intake
¾” G ¾” G ¾” G
Water hardness
Max 3° F Max 3° F Max 3° F
Water pressure
150-300kPa 150-300kPa 150-300kPa
IP degree
IPX0 IPX0 IPX0
Positioning
On countertop or trestle
1 - INTRODUCTION
1.4 - Technical characteristics and data plate
