Gardena R40Li Operator‘s User Manual

64 - English
9. TROUBLE SHOOTING
Continue until only a very short section of the
wire remains which is the difference between a
flashing blue light and a solid green light.
b) If the indicator lamp flashed yellow in test 3b)
above, a similar test is carried out but with the
new loop wire connected to A1 instead.
5. When the break is found, the damaged section
must be replaced with a new wire. The damaged
section can be cut out if it is possible to shorten
the boundary wire. Always use original couplers.

Gardena R40Li Operator‘s Specifications

General

Cutting Width	17 cm
Battery Type	Li-Ion
Area Capacity	400 m²
Weight	7.4 kg
Maximum Slope	25%
Battery Voltage	18 V
