when the subject is within the ideal flash range. To achieve
optimal results, ensure that the subject is positioned within a
range of 10-100 feet (3-30m) from the camera.
Note: The E8PCF model is unique, featuring a close-focus
lens that allows for capturing objects as close as 8 inches
(20cm).
There are two ways to mount the camera: using the provided
adjustable web belt, or the tripod socket.
Using the adjustable strap: In order to use the strap on the
camera, push one end of the strap through the two brackets on
the back of the camera. Thread the end of the strap through the
buckle. Fasten the strap securely around the tree trunk by
pulling the end of the strap firmly so there is no slack left
(Figure 17).
Using the tripod socket: The camera is equipped with a socket
at the bottom end to enable mounting on a tripod or other
mounting accessories with a standard UNC 1/4-20 thread screw
(not included).
Figure 17: Mounting the Camera
