4
which may cause more scratches.
Figure 1: Front View
Install the antenna: The antenna is placed in the accessory
slot on the right side of the package box. Please screw the
antenna into the mounting base on the top of the camera and
securely tighten it (Figure 1).
The E8P, E8PCF and E8P Max models are equipped with
high-performance infrared no-glow 940nm LEDs, which serve
as a flash (invisible to human and animal eyes).
The E8PWF model is equipped with 36pcs high-performance
white flash LEDs, which serve as a flash (visible to human and
animal eyes).
LEDs
Lock Hole
Optics Lens
Central
PIR Lens
Light Sensor
Indicator
Lock Buckle
Antenna
Side PIR Lens
