Page 4
GARDTEC
800 Series
User Manual
4 = Master Allows Setting, Unsetting, Zone Remove (if programmed by
(User 1 always Master) engineer), Test System, View Log, Chime On/Off, User
Codes, Set Time/Date, Reset After Alarm (if programmed
by engineer), Unsetting.
5 = Cleaner Full System Setting (from unset system),
(816 Only) Cleaner Area Unsetting (from set system),
Cleaner Part Set (from part cleaner set system).
Control Code Levels (affecting an output)
Control Allows an output that has been pre-programmed by the installation
company to be operated.
May also have an attribute of Can or Can’t Unset. Control level
codes can never Set a system.
User Code Types
Master Level User Code EN2 (default) - 5678
EN3 (default)- 005678
99 user codes are available offering 19 code types with varying levels of access to the
system. User number 1 will always be a Master Level User but the remaining User
Codes may be programmed (by a Master Code) to the required level of access. These
may be changed at any time via a Master level code
The User Code levels available and the functions available for the levels are:-
Master Allows Setting, Unsetting, Zone Remove (if programmed by
engineer), Test System, View Log, Chime On/Off, User
Codes, Set Time/Date, Reset After Alarm (if programmed
by engineer), Unsetting.
Cleaner Full System Setting (from unset system),
Cleaner Area Unsetting (from set system),
Cleaner Part Set (from part cleaner set system).
Area 1 to 7 User Allows Area 1 to 7 Setting, Area 1 to 7 Part Setting,
Area 1 to 7 Unsetting.
Main User Allows Setting, Part Setting, Zone Remove (if programmed
& Main User 1 to 7 by engineer), System Test, Unsetting, Reset after Alarm (if
programmed by engineer). Main User 1 to 7 are specific to
their area.
Control Used for control of other equipment (see installation
company for details).
Set Only Only Allows for the setting of the system.
