Gared 2500 - Parts List; 2500 Side Fold Wall Mount Parts; Wood Pads for Wall Mount; Parts for Wall Mount with AAG

2500 Wall Mount
6
PARTS LIST
2500 SIDE FOLD WALL MOUNT
EXTENSION
PART NUMBER:
QTY:
DESCRIPTION:
4-6'
6-9'
9-12'
1040-30-00
10 ft
4/O STRAIGHT COIL CHAIN - ZINC
X
1040-30-00
17 ft
4/O STRAIGHT COIL CHAIN - ZINC
X
1040-30-00
24 ft
4/O STRAIGHT COIL CHAIN - ZINC
X
154151696
1 ea
HARDWARE KIT, WALL MOUNT UNITS
X
X
X
154151698
1 ea
CHAIN SUPPORT KIT
X
X
X
154151699
1 ea
SINGLE BRACE KIT
X
154151702
1 ea
SIDE FOLD ADDER KIT
X
X
X
154154093
1 ea
SIDE FOLD ADDER KIT (NARROW NON - AAG ONLY)
X
X
X
501752937
1 ea
MANUAL, 2500 SIDE FOLD WALL MOUNT
X
X
X
504151652
4 ea
PIPE, FU. INNER, 4 -6'
X
504151655
4 ea
PIPE, FU. OUTER, 4 -6'
X
504151653
4 ea
PIPE, FU. INNER, 6 -9'
X
504151656
4 ea
PIPE, FU. OUTER, 6 -9'
X
504151654
4 ea
PIPE, FU. INNER, 9 -12'
X
504151657
4 ea
PIPE, FU. OUTER, 9 -12'
X
504152686
1 ea
INNER SLIDE TUBE A (N ARROW FRAME)
X
504152687
1 ea
OUTER SLIDE TUBE A (NARROW FRAME)
X
504152688
1 ea
INNER SLIDE TUBE B
X
X
504152689
1 ea
OUTER SLIDE TUBE B
X
X
504152690
1 ea
INNER SLIDE TUBE C (WIDE FRAME)
X
504152691
1 ea
OUTER SLIDE TUBE C (WIDE FRAM E)
X
504152692
1 ea
INNER SLIDE TUBE D (NARROW FRAME)
X
504152693
1 ea
OUTER SLIDE TUBE D (NARROW FRAME)
X
504152694
1 ea
INNER SLIDE TUBE E (WIDE FRAME)
X
504152695
1 ea
OUTER SLIDE TUBE E (WIDE FRAME)
X
504151670
2 ea
STRAP BRACI NG, 48" (NARROW FRAME)
X
504151672
2 ea
STRAP BRACING, 69" (WIDE FRAME)
X
504151671
2 ea
STRAP BRACING, 60" (NARROW FRAME)
X
504151673
2 ea
STRAP BRACING, 78" (WIDE FRAME)
X
504151670
4 ea
STRAP BRACING, 48" (NARROW FRAME)
X
504151 672
4 ea
STRAP BRACING, 69" (WIDE FRAME)
X
2500 SIDE FOLD WALL MOUNT - WOOD PADS
FRAME SIZE
PART NUMBER:
QTY:
DESCRIPTION:
504151591
3 ea
WOOD PAD, 3.5" HC, 48"
NARROW FRAME UNITS
504151590
3 ea
WOOD PAD, 3.5" HC, 72"
WIDE FRAME UNITS
2500 SIDE FOLD WALL MOUNT - W/ AAG
FRAME SIZE
PART NUMBER:
QTY:
DESCRIPTION:
153954405
1 ea
KIT, FAN BOARD TO AAG
NARROW FRAME UNITS
153954404
1 ea
KIT, RECT BOARD TO AAG
WIDE FRAME UNITS
154155287
1 ea
NARROW AAG TO WM FRAME KIT
NARROW FRAME UNITS
154155281
1 ea
KIT, AAG TO WM MTG, 4PT RECT
WIDE FRAME UNITS
