Gared 2500 - Kits List; Hardware Kits for Wall Mount Units; Chain Support Kit; Side Fold Adder Kit (Non-AAG)

2500 Wall Mount
7
KITS LIST
HARDWARE KIT, WALL MOUNT UNITS
PART NO. 154151696
QTY.
PART NO.
DESCRIPTION
1
1000-26-00
BANK BOLT HARDWARE KIT
1
1001-26-00
GLASS BOARD GOAL BOLT KIT
2
501-6-16-56
BOLT, CARRIAGE 3/8"x 3 1/2"
4
502-6-16-56Z
BOLT, HEX HEAD 3/8" -16 x 3 1/2"
8
501-6-16-32
BOLT, CARRIAGE 3/8" -16 x 2"
4
502-6-16-40
BOLT, HEX HEAD 3/8" -16 x 2 1/2"
8
502-8-13-56
BOLT, HEX HEAD 1/2" -13 x 3 1/2"
16
504151706
BUSHING, FOLDING UNITS
4
512-6-16-6
SET SCREW, ALLEN FLT PT 3/8"x 3/8"
4
545-6-16Z
NUT, NYLON LOCK NUT 3/8"
8
545-8-13
NUT, NYLON LOCK 1/2" -13 COARSE
8
548-6-16
NUT, WHIZLOCK 3/8"
CHAIN SUPPORT KIT
PART NO. 154151698
QTY.
PART NO.
DESCRIPTION
6
1113-30-00
5/16" QUICK LINK
4
501-6-16-32
BOLT, CARRIAGE 3/8" -16 x 2"
2
504151595
BRACKET, UPPER CHAIN/ PULLEY MOUNT
4
548-6-16
NUT, WHIZLOCK 3/8"
2
7011-11-00
3/8" TURNBUCKLE W/ BOTH EYES
SIDE FOLD ADDER KIT (FAN NON -AAG)
PART NO. 1541540 93
QTY.
PART NO.
DESCRIPTION
1
1030-02-08
LOCKING CLAMP, SIDE SWING WALL MOUNT
4
151651768
KIT, #116 TEE CLAMP
1
2183-02-00
#0183 - 1 7/8" TO 2 3/8"
16
501651854
SPACER BUSHING, 2 1/8" TO 2 3/8"
2
502-8-13-56
BOLT, HEX HEAD 1/2" -13 x 3 1/2"
2
504151 596
HINGE, SIDE FOLD SHORT
2
504151597
HINGE, SIDE FOLD LONG
2
504151600
HINGE, WOODPAD SHORT
2
504151601
HINGE, WOODPAD LONG
4
504151706
BUSHING, FOLDING UNITS
2
504151755
PLATE, BOARD BRACKET
1
504152629
LONG UPPER MOUNT, WALL
1
504152630
SHORT UP PER MOUNT, WALL
1
504152653
SLIDE TUBE WALL BRACKET
1
504152658
SLIDE TUBE BOARD BRACKET
4
504154091
TUBE, SIDE FOLD BRACE (FAN NON - AAG)
1
5042-02-00
1 7/8" MUFFLER CLAMP
2
545-8-13
NUT, NYLON LOCK 1/2" -13 X 2 1/2"
