8.11 FLIGHT DATA LOGGING
NOTE: Some aircraft installations may not provide all aircraft/engine data capable of being logged by the
system.
The Flight Data Logging feature will automatically store critical flight and engine data on an SD data card (up
to16GB)insertedintothetopcardslotoftheMFD.Approximately1,000ighthourscanberecordedforeach
1GBofavailablespaceonthecard.
DataiswrittentotheSDcardonceeachsecondwhiletheMFDispoweredon.Allightdataloggedona
specicdateisstoredinalenamedinaformatwhichincludesthatdate(dataYYYY_MM_DD.csv).Theleis
createdautomaticallyeachtimethePerspective
™
systemispoweredon,providedanSDcardhasbeeninserted.
The status of the Flight DataLoggingfeaturecanbeviewedontheAUX-UTILITYPage.IfnoSDcardhasbeen
inserted,“NOCARD”isdisplayed.WhendataisbeingwrittentotheSDcard,“LOGGINGDATA”isdisplayed.
The.csvlemaybeviewedwithMicrosoftExcel
®
orotherspreadsheetapplications.
ThefollowingisalistofdataparametersthePerspective
™
systemiscapableofloggingfortheSR20andSR22.
•Date
•Time
•GPSaltitude(MSL)
•GPSaltitude(WGS84datum)
•Baro-Correctedaltitude(feet)
•BaroCorrection(in/Hg)
•Indicatedairspeed(kts)
•Verticalspeed(fpm)
•GPSverticalspeed(fpm)
•OAT(degreesC)
•Trueairspeed(knots)
•PitchAttitudeAngle(degrees)
•RollAttitudeAngle(degrees)
•LateralandVerticalGForce(g)
•GroundSpeed(kts)
•GroundTrack(degrees
magnetic)
•Latitude(degrees;geodetic;
+North)
•Longitude(degrees;geodetic;
+East)
•MagneticHeading(degrees)
•HSIsource
•Selectedcourse
•Com1/Com2frequency
•Nav1/Nav2frequency
•CDIdeection
•VDI/GP/GSdeection
•WindDirection(degrees)
•WindSpeed(knots)
•ActiveWaypointIdentier
•Distancetonextwaypoint(nm)
•Bearingtonextwaypoint
(degrees)
•Magneticvariation(degrees)
•AutopilotOn/Off
•AFCSroll/pitchmodes
•AFCSroll/pitchcommands
•GPSx
•GPShorizontalalertlimit
•GPSverticalalertlimit
•SBASGPShorizontalprotection
level
•SBASGPSverticalprotection
level
•FuelQty(right&left)(gals)
•FuelFlow(gph)
•FuelPressure(psi)
•Voltage1and/or2
•Amps1and/or2
•EngineRPM
•OilPressure(psi)
•OilTemperature(deg.F)
•TIT(deg.F)
•ManifoldPressure(in.Hg)
•CHT
•EGT
