Garmin ECHOMAP UHD Manual

Title Using the Race Timer (echoMAP)
Identifier GUID-BD706207-58F2-4C89-823B-CD4506572AB6
Language HR-HR
Description
Version 2
Revision 2
Changes Change to "Menu > Start" or "Menu > Stop" to start and stop the race timer
Status Released
Last Modified 30/11/2020 08:31:28
Author pentecostkare
Korištenje štoperice
1 Na mjeraču pomoći do startne linije odaberite ili kako biste postavili mjerač vremena.
2 Odaberite Izbornik > Početak ili Izbornik > Zaustavi kako biste pokrenuli i zaustavili mjerač vremena.
Title Setting the distance between the Bow and the GPS Antenna (8x0)
Identifier GUID-146C98D7-C18D-456A-97BE-53DB1BFFB92F
Language HR-HR
Description
Version 2
Revision 2
Changes var id tweak
Status Released
Last Modified 12/04/2019 07:17:14
Author gristk
Postavljanje udaljenosti između pramca i GPS antene
Možete unijeti udaljenost između pramca vašeg plovila i GPS antene. Tako ćete osigurati da pramac plovila u
točno određenom trenutku prijeđe startnu liniju.
1 Na mjeraču pomoći do startne linije odaberite Izbornik > Startna linija > GPS pomak pramca.
2 Unesite udaljenost.
3 Odaberite Gotovo.
Jedriličarske značajke 95

Garmin ECHOMAP UHD Specifications

General

Water Rating	IPX7
Routes	100
Sonar	Yes (CHIRP, ClearVü, SideVü)
GPS	Yes
Preloaded Maps	Yes
Network Support	Yes, Garmin Marine Network
Wi-Fi	Yes
Mounting Options	Flush mount
Antenna	Internal
Transmitter Power	500W (RMS), 4000W (peak to peak)
Sonar Frequencies Supported	ClearVü/SideVü: 260/455/800 kHz
Maximum Depth	2, 300 ft (freshwater)
Wireless Connectivity	Wi-Fi
