Garmin ECHOMAP UHD Manual

Title Connector View (echoMAP Plus 6x)
Identifier GUID-D2CCDC40-2CCC-4887-BED3-52006D5ADB5F
Language HR-HR
Description
Version 1
Revision 2
Changes ES-XM and FR-FR has an error
Status Released
Last Modified 20/01/2021 09:17:42
Author gristk
Pregled priključaka uređaja ECHOMAP UHD 60
POWER Napajanje i dijeljenje podataka
1
N2K NMEA 2000
®
mreža
XDCR 4-pinska sonda
OBAVIJEST
Kako ne bi došlo do korozije metalnih spojeva, neiskorištene priključke prekrijte zaštitnim kapicama.
1
Ako ne povezujete NMEA
®
0183 uređaje ili drugi ploter radi dijeljenja podataka, zanemarite plavu i smeđu žicu.
4 Uvod

Garmin ECHOMAP UHD Specifications

General

Water Rating	IPX7
Routes	100
Sonar	Yes (CHIRP, ClearVü, SideVü)
GPS	Yes
Preloaded Maps	Yes
Network Support	Yes, Garmin Marine Network
Wi-Fi	Yes
Mounting Options	Flush mount
Antenna	Internal
Transmitter Power	500W (RMS), 4000W (peak to peak)
Sonar Frequencies Supported	ClearVü/SideVü: 260/455/800 kHz
Maximum Depth	2, 300 ft (freshwater)
Wireless Connectivity	Wi-Fi
