Garmin G5 Electronic Flight
Instrument Part 23 AML STC Installati
on Manual
190
-01112-
10
Rev. 21
Page
178
5.20.1
HSI Co
nfigur
ation
Config Page
Config Option
Configuration Setting
Device
Information
Installation Type
Certified Instrument
Diagnostics/Data Log
Enabled
Attitude Configuration
Ind
icator Type
Normal
Pitch Display
Normal
Roll Display
For Fixed Type Pointers G5 Config =
Ground Pointer
or
For Movable Type Pointers G5 Co
nfig = Sky Pointer
Standard Turn Roll Reference
Hide
Automatic Declutter
Disabled
Air Data
Air Data Sensors
Enabled
Vertical Speed Indicator
(1)(2)
Airspeed
Note: Configure Units prior to
setting airspeeds.
VNE
(1)(2)(3)
VNO
(1)(2)(3)
VSO
(1)(2)(3)
VS1
(1)(2)(3)
VFE
(1)(2)(3)
VA
(1)(2)(3)
VX
(1)(2)(3)
VY
(1)(2)(3)
VG
(1)(2)(3)
VR
(1)(2)(3)
VMC
(1)(2)(3)
VYSE
(1)(2)(3)
Magnetometer
Magnetometer
Enabled
Orientation
Connector Aft
Or
Connector Forward
Or
Connector Port
Or
Connector Starboard
Flight Controls
Garmin Autopilot Servos
None
Analog Autopilot Interface
None
Or
See Section
5.23
if a Non-
Garmin Autopilot is interfaced
Backlight
Current Mode
Automatic
Default Mode
Automatic
Minimum Photocell Input
Default
Minimum Display Brightness
Default
Maximum Photocell Input
Default
Maximum Display Brightness
Default
Filter Time Constant
Default
Display
HSI Page
Enabled
Power Up Page
HSI
Battery
Show Battery Status
When Using Battery
Automatic Power Off
On Ground Only
GPS
Internal GPS Receiver
Disabled
GPS Data Fields
Show
