Garmin G5 Electronic Flight Instrument Part 23 AML STC Installation Manual 190-01112-10
Rev. 21
Page 88
5.
Strip the signal wires approximately 0.17 inches.
6.
Crimp socket contacts (2) on to the signal wires.
7.
Crimp ring terminals (4) on to the shield drain wires.
8.
Repeat steps 1 through 7 as needed for the remaining shielded wires.
9.
Insert the signal wire socket contacts into the appropriate locations in the D-sub connector (5).
10.
Attach the shield drain ring terminals to the connector backshell shield block using the supplied
screws and washers (11)(12)(13).
11.
Wrap the wiring harness with silicone fusion tape (3) at the point where the strain relief clamp (7)
and connector backshell (6) will contact the wiring harness.
12.
Attach the strain relief clamp (7) to the connector backshell (6) using the supplied screws (8).
CAUTION
Placing the concave side of the strain relief clamp across the wiring harness will damage the
wiring harness.
NOTE
Only two ring terminals should be attached to each screw on the connector backshell shield
ground. It is preferred that only two wires be terminated in each ring terminal. This will
necessitate the use of a ring terminal, #8, insulated, 14-16 AWG (MS25036-153). If only a single
wire is left or if only a single wire is needed for this connector a ring terminal, #8, insulated, 18-
22 AWG (MS25036-149) can be used. If more wires exist for the connector than two per ring
terminal, it is permissible to terminate three wires per ring terminal.
13.
Install the connector backshell cover (9) using the supplied screws (10).
This area intentionally blank
