GIA 63 Installation Manual 190-00303-05
Page 4-16 Rev. Y
*Indicates Active Low (Ground to activate)
† Pin not currently supported
58 MAIN OBI SYNC† Out
59 MAIN KING SERIAL DME DATA I/O
60 MAIN KING SERIAL DME CLOCK I/O
61 RESERVED Out
62 MAIN KING SERIAL DME REQUEST Out
63 MAIN KING SERIAL DME ON* OUT† Out
64 MAIN KING SERIAL RNAV REQUEST† In
65 RESERVED --
66 RESERVED --
67 DISCRETE OUT* 1B Out
68 DISCRETE OUT* 2B Out
69 DISCRETE OUT* 3B Out
70 DISCRETE OUT* 4B Out
71 DISCRETE OUT* 5B Out
72 DISCRETE OUT* 6B Out
73 DISCRETE OUT* 7B Out
74 DISCRETE OUT* 8B Out
75 DISCRETE OUT* 9B Out
76 RESERVED --
77 DISCRETE OUT* 10B Out
78 RESERVED --
Table 4-6. P606 (I/O 2) Pin List
Pin Pin Name I/O
