Garmin GNC 255 - Installation Procedures

190-01182-02 GTR 225/GNC 255 TSO Installation Manual
Rev. B Page 4-1
4 INSTALLATION PROCEDURES
4.1 Unit and Accessories
For description of units see Table 1-1.
Table 4-1. Catalog Part Numbers
Table 4-2. Standard Kit Accessories
4.2 Miscellaneous Options
[1] This part is not available from Garmin.
Vendor Contact Information (provided for convenience only):
Amphenol RF, Four Old Newtown Road, Danbury, CT 06810 Phone: 800-627-7100
Model Unit Only Kit Standard Kit Unit P/N
GTR 225 010-00998-00 010-00998-50 011-02718-00
GTR 225A 010-01026-00 010-01026-50 011-02807-00
GTR 225B 010-01027-00 010-01027-50 011-02808-00
GNC 255A 010-01025-00 010-01025-50 011-02806-00
GNC 255B 010-00999-00 010-00999-50 011-02719-00
Model Item Part Number
GTR 225/225A/225B
Connector Kit 011-02721-00
Backplate Assembly 011-02722-00
Mounting Rack 115-01613-00
Product Information Kit K00-00554-10
GNC 255A/GNC 255B
Connector Kit 011-02721-10
Backplate Assembly 011-02722-10
Mounting Rack 115-01613-00
Product Information Kit K00-00554-20
Item Garmin P/N Mfg P/N
GPS 1.57542 GHz Notch Filter 330-00067-00 N/A
Connector, TNC, Male, Clamp N/A 031-4452 [1]
