Garmin GPSMAP 8000 Series User Manual

Yamaha Autopilot Screen
Actual heading
Intended heading (heading the autopilot is steering toward)
Yamaha Autopilot Settings
From a Yamaha engine screen, select Options > Autopilot Setting.
Pattern Set: Allows you to select an autopilot pattern.
Direction: Sets a port or starboard direction for the pattern.
Spacing: Sets the spacing for the pattern.
Length: Sets the length of the pattern.
Amplitude: Sets the angle for the zigzag pattern.
Initial Radius: Sets the radius of the spiral pattern.
Final Track Point Mode: Sets the mode for the autopilot when it reaches the end of a route. The FishPoint®
option maintains the position, but does not maintain the heading. The DriftPoint® option allows the boat to
drift with the wind or current while maintaining the selected heading, but does not maintain the position. The
StayPoint® option maintains the position and the heading. The Deceleration option stops the motor, but does
not maintain the position or heading. The No Deceleration option does not stop the motor.
Course Hold Offset: Sets a distance to navigate parallel to a route.
NOTE: Detailed information on the operation of the Yamaha Joystick and Autopilot system can be found in the
Quick Guide included with the latest Joystick/Autopilot kit.
Autopilot 119

Garmin GPSMAP 8000 Series Specifications

General

Display Size	12" or 16"
Water Resistance	IPX7
Power Supply	10-32 VDC
Built-in Sonar	No
MicroSD Card Slot	Yes
Display Type	Multi-touch display
Connectivity	Wi-Fi, Bluetooth, NMEA 2000
Chart Compatibility	BlueChart g3, LakeVü g3
Video Input	Yes, supports video input from cameras
CHIRP Sonar	Yes, when connected to compatible transducer
CHIRP ClearVü	Compatible with ClearVü transducers
CHIRP SideVü	Compatible with SideVü transducers
Dimensions	Varies by model
Weight	Varies by model
