Specifications
Ice Fishing Bundle Specifications
Battery type Sealed, lead acid, 12Ah
Battery life
Up to 7hr.
NOTE: The actual battery life of a fully charged battery can vary based on the device
used, backlight brightness, temperature the battery is operated and stored in, age of
the battery, and depth of the water.
Battery discharge at
0°C (32°F)
5.6 hr. with screen brightness at 100%, 7.5 hr. at 50%
Battery shelf life after
charging
1 mo.: 92%
3 mo.: 90%
6 mo.: 80%
Battery operating
temperature range
From -15° to 50°C (from 5° to 122°F)
Battery charging
temperature range
From -15° to 40°C (from 5° to 104°F)
Battery storage
temperature range
From -15° to 40°C (from 5° to 104°F)
Physical size,
assembled kit with
device (L × W × H)
35 × 31 × 33cm (13.8 × 12.2 × 13.0in.)
Weight without
device
8.68kg (19.15lb.)
LVS34 Specifications
Dimensions (L x H x W) 161.7 x 77.5 x 47.8mm (6.37 x 3.05 x 1.88in.)
Weight (transducer only) 1018 g (2.25 lb.)
Frequencies From 530 to 1,100 kHz
Operating temperature From -10° to 40°C (from 14° to 104°F)
Storage temperature From -40° to 85°C (from -40° to 185°F)
Maximum depth/distance
1
61 m (200 ft.)
Field of view
Front to back: 135 degrees
Side-to-side: 20 degrees
1
Dependent upon water salinity, bottom type, and other water conditions.
