Weight 3-3.7 kg without cable (depending on product variant)
Cable length (fixed cable version) 4.5 m/8 m
Size single version charging station, height*width*depth 340*240*150 mm
Size double version charging station,
height*width*depth
340*495*145 mm
Rated current withstand 10 kA
Rated short-time withstand current 10 kA
Rated conditional short-circuit current of an assembly 10 kA
Short-circuit protective device type C
Rated impulse withstand voltage 4 kV TBC
Rated insulation voltage 230 V/400 V
Rated diversity factor (RDF) 1
Pollution degree 3
EMC environmental condition A and B
RFID Frequency Band 13.56 MHz TBC
RFID output power 250 mW TBC
SIM 3 FF = Micro = 15x25 mm
Modem Lte Cat M1/Cat Nb2/Egprs
Wi-Fi 802.11 g 2.5 GHz
Maximum pre-fuse to terminal 80 A
Installation power cable limitations Maximum 16 mm
2
, outer diameter: maximum 24 mm
2
Power connection terminals 16 mm
2
, spring type
86
Technical data
