Warranty 2 years
Design product life cycle 10 years installation/30 000 hours charging at 20 C
8.2 LOAD INTERFACE TECHNICAL DATA
Standards/directives IEC 12345
EMC Classification 2014/30/EU
Installation method DIN rail.
Installation environment Indoor/outdoor electrical cabinet.
Location type Restricted access.
Rated voltage TN/IT/TT 1-phase 230 VAC 50 Hz
Rated current 13 mA
Installation systems TT, IT and TT system.
Power <3W
Protection class IP20
Temperature range -20 °C to +50 °C
Weight 0.2 kg
Dimensions (heightxwidthxdepth) 86x72x49 + antenna mm (4 DIN modules).
Color Grey
Recommended protective pre-fuse max. C 10 A
Overvoltage category III (OVC 3)
Rated impulse withstand voltage 4 kV
Rated insulation voltage 230 V/400 V
Antenna connection SMA male.
87
Technical data
