Garrett CSI 250 - Page 6

7. Insert the Cable into the Connector of the Control
Housing and hand-tighten.
8. The location of the Arm Cuff may be adjusted by
removing the screw on the bottom and rotating the
Arm Cuff 180°. Figure 1-8.
9
CSI 250
5. Depress the Spring Clip in the Lower Stem to
adjust to the most comfortable operating length.
Figure 1-5.
6.Wrap the Searchcoil cable snugly about the stem
with the first turn of the cable over the stem.
Figure 1-6.
8
Garrett Metal Detectors
Figure 1-7
Figure 1-5
Figure 1-6
Figure 1-8
