GarrettCom Magnum CS14 Series User Manual

CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
9
www GarrettCom com ..
LED Indicators (Dual: front and top)
POWER: Steady ON when power applied
10/100: Steady ON for 100Mbps; OFF for 10 Mbps
LK/ACT: Steady ON for LINK (LK) with no traffic, BLINKING indicates
port is transmitting / receiving (ACT).
F/H: Steady ON for full-duplex, OFF for half-duplex
Mounting options
Metal mounting clips for panel mounting: included
DIN-Rail mounting option: Model # DIN-RAIL MC2 (see Section 3.4)
Rack-mount option: MC14-TRAY, see
http://www.garrettcom.com/mc_tray.htm
Mean Time Between Failure
(MTBF) – over15 years, Telcordia (Bellcore) Method

GarrettCom Magnum CS14 Series Specifications

General

Brand	GarrettCom
Model	Magnum CS14 Series
Category	Switch
Language	English
