CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
39
www GarrettCom com
..
The compact and lightweight design of the Magnum CS14 and CSN14 Series
allows it to be easily installed in almost any location. A Velcro strip may be used for
mounting the unit on a vertical surface such as a wall or cabinet, or for securing the unit on
a table-top or shelf. Alternatively, metal mounting clips and screws are included for a
rugged and secure mounting in any orientation.
Installation of the Magnum CS14 and CSN14 Series Converter Switches is a simple
procedure. The installation location is dependent upon the physical layout of the Ethernet
network and associated cabling. Make sure the unit is installed in a location that is easily
accessible to an AC power outlet or the appropriate DC source and where cooling is not
inhibited. The green Power (PWR) LED must turn ON when power is applied.
