CS14, CSN14 Series Converter Switch Installation and User Guide (02/06)
v
www GarrettCom com
..
3.7 CS14H and P Series , DC-powered, Installation .............................. 48
3.8 Connecting Ethernet Media ............................................................... 49
3.8.1 Connecting Twisted Pair............................................................ 51
3.8.2 Connecting Fiber Optic ST-type, “twist-lock”........................... 52
3.8.3 Connecting Fiber Optic SC-type, "Snap-In".............................. 53
3.8.4 Connecting Single-Mode Fiber Optic........................................ 53
3.8.5 Power Budget Calculations for CS14 Series, Fiber Media........ 54
3.8.6 Connections to NICs which support Auto-Neg RJ-45 ports...... 56
4.0 OPERATION ....................................................................................... 57
4.1 Dual-Speed Functionality, and Switching ......................................... 57
4.2 Auto-cross (MDIX), Auto-negotiation and Speed-sensing................ 59
4.3 (F- H) Switch, Full-Duplex or Half-Duplex options for Fiber port# 1. 60
4.4 Dual LEDs, Front-panel and side-panel (Magnum CS14 and CSN14)61
5.0 TROUBLESHOOTING ...................................................................... 62
5.1 Before Calling for Assistance............................................................ 63
5.2 When Calling for Assistance ............................................................. 65
5.3 Return Material Authorization (RMA) Procedure............................. 66
