Garrison 043-6127-2 User Manual

10
Model No. 043-6127-2/043-6128-0/043-6129-8/043-6130-2/043-6131-0/043-5499-2 | Contact us: 1-800-268-6591
4. Open the window.
5. Measure the window opening.
• If the window opening is too narrow for the window slider kit, remove the inner
slider section from the window slider kit.
A. Inner slider section
B. Outer slider section
• Using a saw, cut the inner slider section to ft the window opening.
• Slide the inner slider section into the outer slider section of the window slider kit.
6. Place the window slider kit into the window, extending it to ft the width of the window.
Be sure the rain cover is on the outside of the window.
Installation Instructions
A
B
NOTE: For casement window installation, the window slider kit may be installed
vertically with the window slider kit opening at the bottom.

Garrison 043-6127-2 Specifications

General

Brand	Garrison
Model	043-6127-2
Category	Air Conditioner
Language	English
