SERVICE WORK ON THE CHASSIS 11
59
11.24 Removing the air filter
Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Only operate the vehicle if it is equipped with an air filter.
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the appli-
cable regulations.
Preparatory work
–
Remove the air filter box cover. ( p. 57)
A00783-10
Main work
–
Detach retaining tab
1
.
– Remove air filter with air filter support.
– Remove air filter from air filter support.
11.25 Cleaning the air filter and air filter box
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the appli-
cable regulations.
Info
Do not clean the air filter with fuel or petroleum since these substances attack the foam.
Preparatory work
–
Remove the air filter box cover. ( p. 57)
–
Remove the air filter. ( p. 59)
F01027-01
Main work
– Wash the air filter thoroughly in special cleaning liquid and allow it
to dry properly.
Air filter cleaner ( p. 131)
Info
Only press the air filter to dry it, never wring it out.
– Oil the dry air filter with a high-grade air filter oil.
Oil for foam air filter ( p. 131)
– Clean the air filter box.
– Clean the intake flange and check it for damage and tightness.
