WHEELS, TIRES 13
87
13.1 Removing the front wheel
Preparatory work
–
Raise the motorcycle with a lift stand. ( p. 44)
A00830-13
Main work
– Manually press the brake caliper toward the brake disc to push back
the brake pistons.
Info
Make sure that you do not press the brake caliper against
the spokes when pushing back the brake pistons.
A00839-10
–
Loosen screw
1
by several rotations.
–
Loosen screws
2
.
–
Press on screw
1
to push the wheel spindle out of the axle clamp.
–
Remove screw
1
.
A00840-10
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the brake
disc is not damaged.
– Hold front wheel and remove wheel spindle. Take the front wheel
out of the fork.
Info
Do not actuate the hand brake lever when the front wheel is
removed.
H00934-10
–
Remove spacers
3
.
