20 TECHNICAL DATA
112
Info
Do not use on sandy terrain.
20.3.2 Basic carburetor setting for sandy surfaces
Idle air adjusting screw 2 turns
Idling jet 48
Jet needle NRJ C
Needle position 4th position from top
Main jet 148
Info
If the engine is not running smoothly, use a smaller main jet.
20.4 Capacities
20.4.1 Gear oil
Gear oil 0.50 l (0.53 qt.)
Engine oil (15W/50) ( p. 117)
20.4.2 Coolant
Coolant 0.8 l (0.8 qt.)
Coolant ( p. 117)
20.4.3 Fuel
Fuel tank capacity, approx. 5.2 l (1.37 US gal) Super unleaded (98 octane) mixed with
2-stroke engine oil (1:40) ( p. 118)
20.5 Chassis
Frame Central tube frame of chrome molybdenum steel tubing,
powder-coated
Fork WP Suspension XACT 5543
Shock absorber WP SuspensionXACT 5746
Suspension travel
front 278 mm (10.94 in)
rear 305 mm (12.01 in)
Fork offset 14 mm (0.55 in)
Brake system
front Disc brake with 2-piston brake caliper
rear Disc brake with 1-piston brake caliper
Brake discs - diameter
front 240 mm (9.45 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 3.5 mm (0.138 in)
rear 3.7 mm (0.146 in)
Offroad tire pressure
front 1.0 bar (15 psi)
