6 CONTROLS
16
6.7 Fuel tap
S04318-10
The fuel tap is on the left side of the fuel tank.
Using the tap handle
1
on the fuel tap, you can open or close the fuel
supply to the carburetor.
Possible states
Fuel supply closed OFF Fuel cannot flow from the fuel tank to the
carburetor.
Fuel supply open ON Fuel can flow from the fuel tank to the car-
buretor. The fuel tank empties completely.
6.8 Choke
S04319-10
Choke
1
is fitted on the left side of the carburetor.
Activating the choke function frees a drill hole in the carburetor through
which the engine can draw extra fuel. This results in a richer fuel-air mix-
ture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
Choke function activated The choke lever is pulled out to the
stop.
Choke function deactivated The choke lever is pushed in to the
stop.
6.9 Shift lever
401950-10
Shift lever
1
is mounted on the left side of the engine.
