5
SERIAL
NUMBER
S
12
5.1
Vehicle
identification
numb
er
401945-10
The
vehicle
identification
number
1
is
stamped
on
the
right
side
of
the
steering
head.
5.2
Type
label
402154-10
Type
label
1
is
located
on
the
front
frame
tube.
5.3
Engine
number
401949-10
The
engine
number
1
is
located
on
the
left
side
of
the
engine
under
the
engine
sprocket.
5.4
Fork
part
number
401947-10
Fork
part
number
1
is
stamped
on
the
inner
side
of
the
axle
clamp.
13
