11 SERVICE WORK ON THE CHASSIS
58
Main work
–
Check the throttle cable routing. ( p. 63)
S04346-11
– Position the fuel tank and fit the two spoilers to the sides of the radi-
ator mount.
– Make sure that no cables or throttle cables are trapped or damaged.
S04345-11
–
Mount and tighten screw
1
with the rubber bushing.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
S04344-11
–
Mount and tighten screws
2
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
– Mount fuel hose.
– Position the fuel tank breather in the steering stem.
Finishing work
–
Mount the seat. ( p. 52)
11.32 Checking for chain dirt accumulation
400678-01
– Check the chain for coarse dirt accumulation.
» If the chain is very dirty:
–
Clean the chain. ( p. 59)
