Gasmate RIO BBQ - BBQ Components and Assembly

8
9
BARBECUE COMPONENTS
1. BarbecueBody&RoastingHood
2. RightHandPlate(Smooth)
3. LeftHandPlate(Ribbed)
4. DripTray
5. SupportPost
6. IntegratedSideHandlesandLegs
7. Bolts/WingNutsx4
8. FootCrossUpper
9. FootCrossLower
10.WingScrewsx3
11.RegulatorandHoseAssembly
12.CylinderRetentionCord
2
3
4
5
8
9
10
1
11
12
6
7
NOTE
Removeanytransitprotectionmaterial.
FRONT
