Gates MC3001 - Page 11

USE USER GUIDE – MC3001
8
7
3
6
5
4
1
2
1. Crimper flange face 5. Disengage die button
2. Gauge setting mechanism 6. On button
3. Finished crimp indicator light 7. Emergency stop button
4. Engage die button 8. Mains on/off switch
Fig 4.a : Identification diagram
11
