USER GUIDE – MC3001
4.2. – SPARE PARTS:
Note: Tampering with the machine during the warranty period will render the latter void.
All orders for spare parts must state reference, description and quantity required.
Example:
Reference: MC3000-4622
Description: PISTON
Quantity: 1
4.2.1 – SPARE MACHINE PARTS (see Figure 11):
Position REF. Description P/N Quantity
Pos. 4 / fig. 1 MC3000-004 Control Valve 7482-19987 1
Pos. 6 / fig. 1 MC3001-11104 Gear Pump 8000-10082 1
Pos. 10 / fig.11 MC3000-127 Oil trap ring 7482-19717 1
Pos. 9 / fig. 11 MC3000-1283 Piston flange 7482-19718 1
Pos. 2 / fig. 3 MC3000-1512
MC3000-9574
Thermical circuit breaker 3-phase
Thermical circuit breaker 1-phase
7482-19719
7482-19963
1
Pos. 8 / fig. 11 MC3000-152 Composite seal ø 190 mm 7482-19720 1
Pos. 14 / fig. 11 MC3000-154 Composite seal ø 200 mm 7482-19721 1
Pos. 5 / fig. 11 MC3000-189 Piston ring 7482-19722 1
Pos. 7 / fig. 11 MC3000-190 Piston flange ring 7482-19723 1
Pos. 12 / fig. 3 MC3000-20 Electrical transformer 7482-19724 1
Pos. 4 / fig. 11 MC3000-291 O’ring R No. 67 7482-19725 1
Pos. 16 / fig. 11 MC3000-343 CHC M14*50 12-9 screw 7482-19726 12
Pos. 3 / fig. 11 MC3000-4622 Piston 7482-19727 1
Pos. 15 / fig. 11 MC3000-4640 Head flange 7482-19728 1
Pos. 1 / fig. 3 MC3000-005 Motor 3Kw 380V 3Ph 7482-19729 1
Pos. 1 / fig. 11 MC3001-11409 Master die 8000-10091 1
Pos. 13 / fig. 11 MC3000-59 Head 7482-19731 1
Pos. 5 / fig. 3 MC3000-762 Fuse 4A gi 7482-19732 1
Pos. 4 / fig. 3 MC5000-766 Fuse 0,50 A am 7482-19037 1
MC3000-82 Pilot valve (machines before 1173) 7482-19734 1
Pos. 14 / fig. 3 MC3000-946 Contactor 7482-19735 1
MC3000-HEAD Standard exchange crimping head 7482-19352 1
MC5000-1419 Body’s switch of push button 7482-19740 1
Pos. 6 / fig. 11 MC5000-153 Composite seal ø 260 mm 7482-19742 1
MC5000-1666 Signal’s body 7482-19743 1
MC3001-11192 Magnetic die changing tool 8000-10083 1
Pos. 1 / fig. 4 MC5000-21 Revolution counter button 7482-19228 1
MC5000-36 Bulb 7482-19665 1
Pos. 18 / fig. 11 MC5000-4553 Tightening ring 7482-19226 8
Pos. 11 / fig. 11 MC5000-4586 Gauge 7482-19143 1
MC3001-10432 Die retaining pin 8000-10085 8
MC3001-10433 Die retaining pin 8000-10090 8
MC5000-11110 Die Pin B 8000-10066 1
Pos. 2 / fig. 11 MC5000-5036 Spring master dies 7482-19231 16
Pos. 17 / fig. 11 MC5000-54 Die nipple 7482-19033 8
Pos. 2 / fig. 1 MC5000-5691 Pressure limiter (machines after 1173) 7482-19986 1
Pos. 13 / fig. 4 MC5000-10428 Protection gauge 8000-10081 1
Pos. 3 / fig. 4 MC5000-5845 Main contactor 7482-19985 1
Pos. 13 / fig. 3 MC5000-6004 ON (lit) push button 7482-18510 1
Pos. 7,8 / fig. 3 MC5000-6005 Green push button 7482-18509 2
Pos. 16 / fig. 3 MC5000-6008 Emergency stop 7482-19675 1
Pos. 11,15/ fig. 3 MC5000-6009 Yellow signal 8000-10013 1
MC3001-10182 Set of 8 foam pads 7482-19766 1
