USER GUIDE - MC3001
4
2 - DESCRIPTION
2.1 - GENERAL:
You have just acquired a GATES MC3001 powered crimper. It is necessary you adhere to the enclosed instructions
for best performance. The MC3001 has been designed specifically for crimping Gates hoses and couplings which
are used constantly in today’s industry, agriculture and public works. This user guide contains all information
concerning the operation, use and maintenance of your MC3001.
2.2 - CHARACTERISTICS:
Crimping power: 210 tonnes (maximum measured).
Pressure:305 bar during crimping, 150 bar during retraction.
Motor: 3 kW, 8 A at 380 V 3-phase.
4 kW, 26 A at 220 V 1-phase.
Dimensions:H 650 x W 390 x L 640 mm.
Weight: 180 kg with oil.
Capacity: braided hose from 3/16" to 1" 1/4
multiple-plied metal reinforced hose from 1/4" to 1 1/4" (not skived)
Noise levels: 71 dB.
Oil tank: 10 litres.
Pump: gear type.
Die travel: 14 mm working travel and 38 mm maximum travel.
Adjustment: by micrometer screw with numerical display and electrical stop.
Crimping: by pressing push-button.
Crimping stop: automatic according to adjustment.
Retraction: by pressing push-button.
Retraction stop: by releasing push-button.
Cycle time: 12 seconds for 3-phase 380 V crimper.
16 seconds for 1-phase 220 V crimper.
Tooling: GATES die sets.
These specifications are nominal and must not be used for inspection.
Options:-Machine table + die rack + quick change tool
(ref. MC5000 - 10798)
-Quick change tool + die rack
(ref. MC5000 - 10354)
